Power
Top Speed: 14.5mph Speed controller installed(Limit can be removed or disconnected)
- Engine: 4-stroke, V-twin, SOHC, liquid-cooled
- Displacement: 749cc
- Bore x Stroke: 85.0 x 66.0mm
- Compression Ratio: 9.3:1
- Maximum Torque: 42.7 lb-ft @ 4750 rpm
- Fuel System: DFI® with two 36mm throttle bodies
- Ignition: Digital DC-CDI
- Transmission: Automatic CVT (H,L,N,R)
- Final Drive: Selectable 2WD/4WD with variable control front differential lock, shaft
Capability
- Front Suspension / Wheel Travel: Double wishbone/6.7 in
- Rear Suspension / Wheel Travel: Double wishbone/7.5 in
- Front Tire: AT 25 x 8-12
- Rear Tire: AT 25 x 10-12
- Front Brakes: Dual hydraulic 176mm discs with 2-piston calipers
- Rear Brakes: Sealed, oil-bathed, multi-disc with independent park brake
- Ground Clearance: 9.4 in
- Starting System: Electric
- Fuel Capacity: 5.0 gal
- Electronic Power Steering (EPS): Yes
- Turning Radius: 10.5 ft
- Towing Capacity: 1250 lb
- Total Rack Capacity: 242.0 lb
- Rack Capacity, Front/Rear: 88.0/176.0 lb
- Lighting: 35W headlights, 5W taillight, 21W stoplight
Details
- Frame Type: Double-cradle, high-tensile tubular steel
- Track Front/Rear: 36.4/35.0 in
- Overall Length: 86.4 in
- Overall Width: 46.5 in
- Overall Height: 48.0 in
- Seat Height: 35.8 in
- Curb Weight: 699.0 lb*
- Wheelbase: 50.6 in
- Instruments: Speedometer, odometer, dual trip meters, fuel gauge, engine temp, clock, hour meter and 2WD/4WD icon, plus indicators for EPS, neutral, belt, and oil pressure
- Color Choices: Fragment Camo Gray
- Warranty: 12 Month Limited Warranty
- Kawasaki Protection Plus™ (optional): 12, 24, 36, or 48 months
