| Engine | |
|---|---|
| Engine Type | Rotax®, V-twin |
| Engine Power |
|
| Cooling System | Liquid-cooled |
| Displacement | 976 cc |
| Fuel System | Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI) |
| Battery | |
|---|---|
| Battery | 12 V (30 A h) |
| Drivetrain | |
|---|---|
| Drivetrain | Selectable Turf Mode / 2WD / 4WD with exclusive Smart-Lok | Driving Assistance: CVT engine braking ECO™ / ECO™ Off / Work modes Speed limiter |
| Transmission | PRO-TORQ CVT with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P |
| Steering | |
|---|---|
| Power | Dynamic Power Steering (DPS) |
| Suspension | |
|---|---|
| Front Suspension | Arched double A-arm with sway bar |
| Front Travel | 12 in. (30.5 cm) |
| Front Shocks | Twin tube gas charged shocks |
| Rear Suspension | Arched TTA with external sway bar |
| Rear Travel | 12 in. (30.5 cm) |
| Rear Shocks | Twin tube gas charged shocks |
| Brakes | |
|---|---|
| Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
| Rear Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
| Wheels & Tires | |
|---|---|
| Wheels | 15 in. cast aluminum | Steering: Adjustable tilt steering |
| Front Tire | XPS Trac Force 30 x 9/10 x 15 in. |
| Rear Tire | XPS Trac Force 30 x 9/10 x 15 in. |
| Dimensions | |
|---|---|
| Overall Vehicle Size (LxWxH) | 158.9 x 65 x 80.9 in. (403.6 x 165.1 x 228.5 cm) |
| Wheelbase | 115.5 in. (294 cm) |
| Ground Clearance | 14 in. (35.6 cm) |
| Cargo Box | 38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm) |
| Capacities | |
|---|---|
| Storage Capacity | Total: 16.9 gal (63.9 L) |
| Cargo Capacity | Box: 1,000 lb (454 kg) / California only: 600 lb (272.2 kg) |
| Towing Capacity | 2,500 lb (1,134 kg) |
| Payload Capacity | 1,700 lb (771 kg) |
| Fuel Capacity | 10.6 gal (40 L) |
| Weights | |
|---|---|
| Estimated Dry Weight | 1,977 lb (897 kg) |
| Winch | 4,500 lb (2,041 kg) winch with roller fairlead |
| Features | |
|---|---|
| Instrumentation | DC outlet (10-A), USB Port (10-A) x 2 |
| Cage Type | Profiled cage ROPS approved |
| Protection Plan | Heavy-duty front steel bumper, HMWPE full skid plate, 2-piece full hard roof, Aluminum rock sliders |
| Hitch/Type | 2 in. hitch receiver |
| Magneto | 650 W |
| Gauges | 7.6 in. wide digital display with keypad |
| Seat Type | Dual VERSA-PRO bolster bench seats with passenger seats flipping up, Adjustable driver seat, underside hooks, reinforced seat skin featuring Lone Star package trims |
| Lights and Safety | |
|---|---|
| Lighting | Front lighting output 140-W, LED tail lights |
| Warranty | |
|---|---|
| Factory Warranty | 1-year BRP Limited warranty |
| Extended Warranty | B.E.S.T. term available up to 30 months |
